Trusted Precision-Made RF Adapter Cable Factory for Global Clients
As a professional brand with 10 years of experience in electronic accessories, we understand your demand for stable device connection. This RF Adapter Cable has passed CE/FCC dual certification, making every device connection a reliable experience with “zero latency”.
RF Adapter Cable | Match 12+ Interfaces | 10M Stable Transmission, Zero Setup Needed
Have you ever had to rework in a conference room due to a mismatched device interface? Have you ever missed the decisive moment in a game due to cable jams? As a 13-year expert in cross-border electronic accessories, we redefine “reliable connection” with this RF adapter that has passed CE/FCC/ROHS triple certification – you only need to choose the length according to the scenario, and we will take care of the problems of stable signal and interface compatibility with our technology.
MCX/MMCX to alligator clip RF test cable
RG316 RF adapter cable MCX male to BNC male
RG316 MCX female to MMCX male adapter cable
RG178 single end welding jumper
RG402/141 semi-flexible RF cable SMA-J to MCX-K male to female adapter cable
SMA to MCX male extension cable 086/RG405 semi-flexible cable coaxial
UF.L to MCX male and female extension jumper RG178/1.13
MCX/TNC-JW-KY jumper MCX male elbow adapter TNC female
LMR100 low loss flexible coaxial BNC to SMB-JK adapter cable
RG178 single-head welding jumper modified extension cord 50-1.5
RG316 MCX female to MMCX female adapter cable
RG316 RF coaxial adapter cable N-type elbow male to MCX female
RG316 RF silver-plated SMB bent female to MCX female feeder connection
RG316 RF coaxial N-type elbow male to MCX male extension feeder
N female to MCX male cable L16-K/MCX-J silver plated adapter cable
50Ω silver plated cable RG316 Q9 female to MCX elbow male
RG316 RF coaxial adapter cable MCX female to BNC male elbow
BNC-J/MCX-K RF connection jumper BNC male to MCX female
Silver-plated RF coaxial cable MCX female to SMA bent female inner pin
RG316 RF cable SMA male to MCX female connector jumper
IPX to MCX male and female extension cable RG178/1.13 feeder
MMCX to BNC adapter cable RG178 coaxial extension cable
MCX male to BNC female four-hole flange 1M RG316 RF coaxial cable
RG316 RF feeder MCX-JW antenna extension cable adapter
BNC female to MCX male coaxial cable Q9 extension cable
RF adapter RG316 extension cable curved male MCX-JW to SMA-K straight
MCX to electronic cable UHF/MMCX tinned connection cable male and female extension cable
50Ω straight male to female thread inner hole RG316 silver-plated shielded coaxial cable
RG405/086 semi-flexible cable MCX male to MCX bend Male to radio frequency
RG405 semi-flexible RF male and female single-ended test line signal transmission line
MCX female to N male high frequency antenna extension cable RG316 silver plated
Custom RF Adapter Cables Catalog
Customized MCX/MMCX to alligator clip RF test cable→
Customized RG316 RF adapter cable MCX male to BNC male→
Customized RG316 MCX female to MMCX male adapter cable→
Customized RG178 single end welding jumper→
Customized RG402/141 semi-flexible RF cable SMA-J to MCX-K male to female adapter cable→
Customized SMA to MCX male extension cable 086/RG405 semi-flexible cable coaxial→
Customized UF.L to MCX male and female extension jumper RG178/1.13→
Customized MCX/TNC-JW-KY jumper MCX male elbow adapter TNC female→
Customized LMR100 low loss flexible coaxial BNC to SMB-JK adapter cable→
Customized RG178 single-head welding jumper modified extension cord 50-1.5→
Customized RG316 MCX female to MMCX female adapter cable→
Customized RG316 RF coaxial adapter cable N-type elbow male to MCX female→
Customized RG316 RF silver-plated SMB bent female to MCX female feeder connection→
Customized RG316 RF coaxial N-type elbow male to MCX male extension feeder→
Customized N female to MCX male cable L16-K/MCX-J silver plated adapter cable→
Customized 50Ω silver plated cable RG316 Q9 female to MCX elbow male→
Customized RG316 RF coaxial adapter cable MCX female to BNC male elbow→
Customized BNC-J/MCX-K RF connection jumper BNC male to MCX female→
Customized Silver-plated RF coaxial cable MCX female to SMA bent female inner pin→
Customized RG316 RF cable SMA male to MCX female connector jumper→
Customized IPX to MCX male and female extension cable RG178/1.13 feeder→
Customized MMCX to BNC adapter cable RG178 coaxial extension cable→
Customized MCX male to BNC female four-hole flange 1M RG316 RF coaxial cable→
Customized RG316 RF feeder MCX-JW antenna extension cable adapter→
Customized BNC female to MCX male coaxial cable Q9 extension cable→
Customized RF adapter RG316 extension cable curved male MCX-JW to SMA-K straight→
Customized MCX to electronic cable UHF/MMCX tinned connection cable male and female extension cable→
Customized 50Ω straight male to female thread inner hole RG316 silver-plated shielded coaxial cable→
Customized RG405/086 semi-flexible cable MCX male to MCX bend Male to radio frequency→
Customized RG405 semi-flexible RF male and female single-ended test line signal transmission line→
Customized MCX female to N male high frequency antenna extension cable RG316 silver plated→
Coaxial Cable Cores: Diverse Materials for Robust Signal Pathways
In RF Adapter Cables, the coaxial cable core is a crucial carrier for signal transmission. Different materials of coaxial cable cores possess unique performances and application scenarios, providing strong support for diverse radio – frequency application requirements.
Coaxial cable series
RG316 HF Micro Series:7×0.175mm silver-plated copper/CCS + 1.53mm PTFE + 1.95mm silver-plated braid (90% coverage) + 2.50mm FEP jacket. Φ2.5mm OD, 15mm bend radius. 2.34dB/m at 6GHz for wearables/drone FPV.
RG405 Semi-Flex Series:0.53mm silver-plated CCS + 1.68mm PTFE + 2.17mm dual-tinned braid + 2.60mm FEP jacket. 6mm single-bend radius, 60GHz cutoff. For medical monitors requiring frequent re-routing.
RG141 Broadband Flex Series:0.94mm silver-plated copper + 2.98mm PTFE + 3.55mm tinned copper braid + FEP/LSZH/PVC jacket. 2.22dB/m at 18GHz, 97W power handling. Balances flexibility/HF performance for test instruments.
LMR100 Entry-Level Micro Series:0.46mm bare copper + 1.50mm LDPE + foil + tinned copper braid + 2.90mm PVC jacket. 50±2Ω impedance, ≤131dB/100m below 3000MHz. Cost-effective micro-connectivity for consumer electronics.
Metal Materials
RG316: 7×0.175mm silver-plated/CCS (2-3μm Ag) → 5% higher conductivity, 345Ω/km resistance, 30% lower skin effect loss at 6GHz. 40% better flexibility.
RG405: 0.53mm silver-plated CCS → 0.72dB/m at 1GHz (25% lower loss vs. bare copper), 50% higher bend-cycle endurance.
LMR100: 0.46mm bare copper → 30% lower cost with stable sub-3GHz performance (e.g., smartwatch antennas).
Insulation Materials
PTFE (RG316/405/141):Dielectric constant=2.1±0.1, Df<0.001, ≥1,500MΩ·km IR (-55~150°C). Thickness (1.53-1.68mm) ensures 50±2Ω impedance, ≤1Ω drift at 6GHz.
LDPE (LMR100):Dielectric constant=2.3, 100±5pF/m capacitance. 40% lower cost than PTFE. -20~80°C range for consumer apps.
Shielding Layers
RG316: 48-carrier 3×16/0.10mm silver-plated braid (92% coverage, Φ1.95mm) → >90dB shielding, >99.9% 6GHz EMI rejection. 5× oxidation resistance, 500h salt spray resistance.
RG405: Dual-tinned braid (Φ2.17mm, 95% coverage) → 15% less signal leakage, 70% lower crosstalk in multi-module micro devices.
LMR100: Longitudinal foil + 80-strand tinned copper braid → 85dB shielding, 40% lower cost vs. full-silver shielding.
Jacket Materials
RG316/405 (FEP):Φ2.50-2.60mm, -55~150°C, 3.4kg tensile strength, 0.15 friction coefficient. 60% less abrasion vs. PVC. Resists oils/solvents.
RG141: FEP/LSZH/PVC options. FEP: 48g/m weight for wearables. LSZH: Low smoke density for enclosed spaces (e.g., car navigation). PVC: 25% cost reduction.
LMR100 (PVC):Φ2.90mm, -20~80°C. Defect-free smooth surface reduces jamming risks, boosts assembly efficiency by 20%.
The following are the models and parameters of our cable products. Click on the thumbnail to view details.
Material & Craft Customization – Tailored for Your Industry Nee
As you browse our RF adapter cables, connectors, and adapters, use this material‑craft guide to choose the optimal build configuration—from conductors and plating to insulation and shielding—for your performance, durability, and application demands.
1. Material Categories by Application
- Gold‑Plated Connectors: Enables low‑loss RF jumper cables up to 6 GHz; corrosion-resistant for test labs and telecom systems (common in “gold-plated RF cable”).
- Nickel‑Plated Connectors: Cost-effective and rugged; suitable for outdoor/industrial RF equipment.
- Braided Copper Shielding: Typically ≥85% coverage, blocking EMI up to −85 dB (IEEE-standard braid coverage).
- PTFE / PE Insulation: Withstands temperatures from –55 °C to +200 °C; ideal for aerospace and rugged applications.
2. Craft Specifications & Performance Impact
- Plating Thickness: Common options like 5 μm (standard) and 10 μm (enhanced reliability) improve corrosion resistance and maintain low insertion loss.
- Shield Braid Coverage: 85% standard vs. 100% for extreme EMI, directly correlating with shielding performance.
- Dielectric Tolerance: Precision-extruded PTFE with ±0.1 mm tolerance supports tight impedance control and stable VSWR.
3. Tailored Material + Craft Combinations
- Kevlar‑Reinforced Jackets: enhance tensile strength and abrasion resistance; ideal for rugged, outdoor, or defense‑grade cable assemblies.
- Medical‑Grade Silicone Jackets: support steam sterilization and biocompatibility for medical connector applications.
- Heavy‑Duty Plating + Shielding: extra‑thick gold plating and dense copper braid for marine, satellite, and harsh EMI environments.
4. Validation & Quality Assurance
- Material Traceability: RoHS, UL, MIL‑STD batch‑lot documentation per MIL‑DTL‑17 standards for high‑reliability builds.
- Performance Reports: includes S‑parameter plots, mating‑cycle durability logs, and thermal‑cycling test data—100% tested per high‑reliability specs.
- Batch Traceability: Each batch of cables is bar coded with a serial or batch number; traceable to manufacturing records and test batches.
Precision manufacturing and customer-focused service
We prioritize efficiency throughout the OEM and custom production process, ensuring a seamless experience. Our focus extends beyond delivering high-quality electronic components to providing exceptional service that meets your expectations.
Flexible Solutions
Tailored options are available to match your specific needs.
Fast Turnaround
Time is valuable, and we are committed to delivering solutions efficiently.
Advanced Manufacturing
We utilize cutting-edge facilities and technologies to ensure product reliability.
Cost-Effective Process
Our one-stop service helps you reduce expenses and maximize profitability.
Make A Sample First？
Designed for space-constrained RF systems, our MCX Adapter Cables deliver DC-18GHz bandwidth with <1.3 VSWR across RG316/RG405/RG141/LMR100 configurations. Featuring ultra-thin 2.5mm OD (RG316) and 6mm static bend radius (RG405), they achieve ultra-low attenuation (<0.27dB/m@500MHz for RG141) via silver-plated copper conductors and triple-layer foil-braid shielding (100dB+ isolation). With 150°C thermal resilience and 3.0kV dielectric strength, these ISO-certified cables excel in IoT wearables, 5G small cells, and medical implants—supporting >100W power@18GHz (RG141) and 60GHz cutoff (RG405). Mitigate micro-connection failures: Test 3 low-cost samples (fully deductible). Claim Your Free Design Simulation Today! – OEM-ready with full RoHS/REACH data sheets.
Quality Inspection Of MCX adapter cable
To bridge cross-border trust gaps, High-definition real-life photos show the quality inspection specialists’ work site in full view – scanning the contact welding accuracy point by point under the eyepiece magnifier, repeatedly checking the calibration parameters in front of the vector network analyzer data screen, and each inspection process is carried out under strict standards. These real-time records from the final inspection link are our visual commitment to product reliability.. Our structured requirement forms streamline communication, while 3 low-cost validation samples (detailed test reports included) mitigate bulk order risks. With a defect rate of 0.15% (vs. industry 1.8%), our premium RF adapter cables redefine precision. Claim your free sample or design rendering today—sample costs apply to bulk orders. Precision isn’t a promise; it’s a 25-point verified standard.
International Certification
You can totally trust us with all certifications shown below.
What is an MCX adapter cable?
An MCX adapter cable is a coaxial cable designed to connect devices with MCX connectors to other RF equipment. These cables are commonly used in high-frequency applications such as wireless communication systems, antennas, test instruments, and other RF devices. The MCX connector offers a compact size and secure connection, making it ideal for tight spaces or low-profile applications.
What payment methods do you accept?
We accept wire transfer, Western Union, and MoneyGram，For more information, please click here
What are the advantages of using an MCX adapter cable?
MCX adapter cables offer several benefits:
Compact Size: Smaller than many other RF connectors, making it ideal for space-constrained applications.
Reliable Performance: Excellent signal integrity with minimal interference.
Wide Frequency Range: Suitable for a broad range of RF applications, typically up to 6 GHz.
Ease of Use: Quick and easy to install with secure connections.
What is the temperature range of the MCX adapter cable?
The operating temperature range for MCX adapter cables typically spans from –20°C to +70°C for most models, although cables with FEP jackets can handle higher temperatures up to 200°C, making them suitable for more extreme environments.
How do I choose the right MCX adapter cable for my application?
Length: Choose between standard lengths (0.5m, 1m, 2m) or custom lengths up based on your project’s requirements.
Connector Type: Select from male-to-male, male-to-female, or right-angle connectors.
Jacket Material: Choose between PVC, FEP, or other materials based on the operating environment’s temperature, flexibility, and chemical resistance needs.
What is your minimum order quantity?
We have no minimum order quantity. We also accept sample orders and can customize the logo, packaging and design of the products. However, we recommend buying more than 100 sets to save shipping costs.
What if the goods received are damaged? How do you solve it?
If the product you received is damaged, please contact us in time. We have a professional team and will solve the problem as soon as possible.
Have a question that doesn't appear here?
If you have searched our Help/FAQ page and still cannot find the answer to your question, please feel free to e-mail us at cc7480917828@gmail.com
Frequently Asked Questions
Welcome to the FAQs on MCX Adapter Cables, where we’ll address your key questions—from defining the product and its advantages to temperature range, selection guidance, and order support. Whether you’re integrating these cables into RF systems, validating specs, or navigating procurement, dive in for insights to make confident, application – aligned decisions.
Custom MCX Adapter Cables – RG316 High-Frequency Coaxial Extension Leads
Optimize signal integrity with our MCX adapter cables, utilizing RG316 high-performance coaxial cable. Designed for 50 Ω impedance, low VSWR, and superior shielding, these cables ensure stable and reliable performance for high-frequency RF applications. Ideal for test equipment, network analyzers, signal generators, and communication systems, they provide precision and durability for your RF testing and connectivity needs.
Constructed with silver-plated copper inner conductors, PTFE insulation, and silver-plated copper braid, these cables offer excellent electromagnetic shielding and low loss across a wide frequency range. The FEP jacket provides additional protection, ensuring the cables perform reliably in demanding environments while maintaining flexibility for easy installation.
Key Features
50 Ω impedance for consistent and accurate signal transmission
Low VSWR (<1.20) for minimal signal reflection and maximum efficiency
Double-layer shielding (aluminum foil and braid) for EMI/RFI protection
High frequency support with minimal attenuation up to 6 GHz
Flexible and durable design for reliable use in tight spaces
These MCX adapter cables are perfect for use in a variety of RF systems, ensuring high-performance signal transmission in environments where reliability and flexibility are critical. Contact us to discuss custom lengths, configurations, and connector options, and optimize your RF projects with precision, durability, and tailored performance.
